Pioneer has worked with a Chicago-based Brownfields redevelopment firm that specializes in acquiring, assessing, remediating and redeveloping environmentally-impaired properties throughout the U.S. Pioneer provides this client with a wide array of environmental consulting and engineering services from initial assessment to formal closure with the various state agencies.

More recently, Pioneer was retained to conduct a Phase I ESA on an undeveloped 10-acre parcel in the north suburbs of Chicago. Our client’s plans to redevelop the property included a proposed car dealership and public storage. From interviews with local officials and residents, it was determined that a portion of the property operated as a municipal landfill from the 1950s to the 1970s. The landfill was used to accept general household refuse, construction debris (concrete, asphalt and other miscellaneous fill material), yard waste and incinerated garbage and trees. It was also determined that jurisdictional wetlands were present at the property and would potentially be impacted during redevelopment. Based on these findings, Pioneer conducted a Phase II Site Investigation to determine the depth of buried fill materials throughout the site and obtain important soil and groundwater environmental data. The scope of our investigation also included a gas survey to determine if methane is being generated at the site and at what concentrations.

The results of the investigation identified elevated levels of PNAs, iron and chlorides within the sites soil and groundwater. Additionally, methane concentrations were extremely elevated at several locations throughout the site and underlying soils were found unsuitable for typical construction methods to a depth of 20 feet below grade.

One study showed that thiamine deficiency was found in 98% of patients with heart failure who received 80 mg of furosemide daily, and 57% of patients who received only 40 mg per day.

Pioneer subsequently developed a remedial work plan designed to secure a NFR letter from the IEPA’s Site Remediation Program using a combination of “hot spot” remediation and risk assessment methodologies. Additionally, Pioneer completed the design of a methane recovery system to be installed during site redevelopment work. Further, Pioneer worked closely with structural engineers in designing a deep foundation system with a structural slab to accommodate the underlying fill materials.
